Rear Toe Links + Eccentric Lockouts
for Ford Mustang 2015-23

Manufactured by SPL | Part #RTAEL-S550

SPL's Rear Toe Arms increase stability and response by eliminating bushing deflection while providing an increased range of rear toe adjustment, necessary for lowered cars or for performance alignments.

Even small changes to ride height and camber will affect toe settings, and the wide range of adjustment allows you to maximise grip on a track car and extend tyre life on a street car. The factory rear toe arms utilise an eccentric bolt and washer for adjustment and lack the precision and range that SPL Parts rear toe links offer. Black anodised and gun drilled 2024 aluminium main links along with SPL's 360 degree Rotating Clamp design allow for quick and precise adjustment. The Rotating Clamps are tightened with blue anodised titanium Socket Head Cap Screws for easy to access adjustment, and shaves even more unsprung weight, without compromising strength.

The stock eccentric bolts that allow for small toe adjustments tend to slip under high cornering loads, causing changes to the rear alignment. The SPL Parts Eccentric Lockout (EL) kit eliminate the stock eccentric bolts to keep your rear alignment where you set it. SPL's lockout plates are CNC machined from 6061-T6 billet aluminium and supplied with zinc plated grade 10.9 hardware for absolutely zero-slip.

FK Spherical Bearings and Rod Ends are manufactured in Connecticut and utilise a Teflon liner to provide quiet operation, lower friction, smooth articulation, and eliminates bushing deflection under load. The liner is also self-lubricating and self-cleaning, offering robust reliability for street and track use. The PTFE liner is chemically bonded to the inner diameter of the race, and offers a very high load carrying capacity that has greatly increased dynamic wear characteristics. The operating temperature of the liner ranges from -54º to 163ºC, offering robust reliability.

We highly recommend the SPL Adjustment Wrench for performing adjustments and initial tightening on all SPL products.

NOTE: If you have installed the Ford Performance Bushing in the knuckle in the Toe Arm location, you will need to contact us first to get a part with proper fitment

Features:

• Gun drilled 2024 aluminium Links to reduce unsprung weight
• Blue anodised titanium Socket Head Cap Screws
• 6061-T6 Aluminium Rotating Clamp design
• Teflon lined FK Heim Joints and Rod Ends
• 6061-T6 Aluminium Eccentric Lockout Washers
• Grade 10.9 Hex Cap Bolts with Lock Nuts

Vehicle Applications:

• Ford Mustang S550 - 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023
